Pex Tee


Features

  • An alternative way of supplying water than Copper Pipe
  • Avoiding soldiering by using either a ring or a sleeve to clamp tighten on the pipe
  • Required a pex clamper and ring to join the pipe. (Sold Seperately)
  • Providing an easier way to work with than copper pipe as it has more flexibility.
  • Offers high heat-resistance and long-term durability.
  • PEX = Cross-linked polyethylene
  • More resistant to breakage caused by freezing than both copper or PVC pipe.
  • PEX conserves energy by reducing heat transfer, or loss of heat through the pipe wall.
  • PEX is more resistant to scale buildup and the resulting loss of flow through the pipe.
  • Lower cost than copper pipe system in both material and installation cost.
  • Developed in the 1960s.
  • Must be kept away from contact with flame or extreme heat, and it must not be exposed to direct or indirect UV light.
  • Do not install PEX in contaminated soils, and do not use pipe thread compounds or mineral- or oil-based products, as these materials can alter the pipe’s characteristics and can damage the pipe fittings.
  • PEX is not approved for installation near hazardous waste disposal sites or petroleum storage tanks.

    Part No Description
    PEXT-05 Pex Tee 1/2"
    PEXT-07 Pex Tee 3/4"
    PEXT-10 Pex Tee 1"
    PEXRT-070705 Pex Reducing Tee 3/4" x 3/4" x 1/2"
    PEXRT-070505 Pex Reducing Tee 3/4" x 1/2" x 1/2"
    PEXRT-070507 Pex Reducing Tee 3/4" x 1/2" x 3/4"
    PEXRT-050507 Pex Reducing Tee 1/2" X 1/2" X 3/4"
    PEXRT-050705 Pex Reducing Tee 1/2" X 3/4" X 1/2"
    PEXRT-101007 Pex Reducing Tee 1" X 1" X 3/4"
    PEXRT-101005 Pex Reducing Tee 1" X 1" X 1/2"
    PEXRT-100707 Pex Reducing Tee 1" X 3/4" X 3/4"
